HIX SubliPro

FREE wraps offer when you purchase this product! Get 7 free standard mug wraps HIX sublimations wraps (a $235 value) with the purchase of the HIX SubliPro Counter Top Mug Oven for a limited time only! Mug wraps will be automatically added to your order (additional freight costs may apply). Call us at 1-800-562-7760 for all the details!

The HIX SubliPro CounterTop oven provides business owners an easy alternative to introduction mass production to your workflow when creating dye-subimation drinkware, such as standard 11/15oz mugs, shot glasses, travel mugs, and pint glasses. It features a porcelain enamel on steel oven interior, measuring 15 1/4" (w) x 21" (d) x 20" (h) for producing as many as 12-15 mugs per cycle or more than 48 per hour. Furnished with nine position nickel plated rack guides and four nickel platted racks, the Hix SubliPro CounterTop Oven can accomodate a variety of substrates of varying heights and diameters.

The oven chamber is heated by enclosed tubular heating elements rated at 7.5KW with air circulated by a two-speed 1/3 HP permanently-lubricated oven blower motor. The oven is enclosed with stainless steel, and has insulation applied to the top, rear, both sides, and bottom - as well as an insulated stainless steel door with double pane window.

The SubliPro CounterTop comes with a solid state temperature control, adjustable from 200° to 500°F and a 60 minute electrical timer with continuous buzzer. Press requires 208/240volt, 60Hz, 1 or 3 phase electrical supply.

Features:

• Nine position rack guide and four nickel-plated loading racks



• Stainless steel rear enclosure panel, front, sides, top, and door with double-pane window



• Cool to the touch oven door handle



• Stainless steel oven door gaskets



• Oven interior liners are porcelain on steelOven cool switch for rapid cooldown when door is open



• Solid state temperature control adjusts from 200° to 500°F



• 7.5 kW input



• 60 minute electric timer with time expired buzzer



• 1/3 HP two-speed fan motor



• UL Certified



• 1 year limited warranty

Specifications:

• Oven chamber: 5 1/4" (w) x 21" (d) x 20" (h)



• Total watts: 8.0KW (including blower motor)



• Volt/Amp/Phase: 208V / 38A / 1 phase
  208V / 23A / 3 phase
  240V / 33A / 1 phase
  240V / 19A / 3 phase



• Temperature range: 200° to 500° F



• Fan power: 1/3 HP



• Oven dimensions: 30" (w) x 28 1/2" (d) x 29" (h)



• Oven weight: 218 lbs



• Shipping dimensions: 33" (w) x 33" (d) x 36" (h)



• Shipping weight: 271 lbs



• Shipping: Free shipping not included - please contact us for a freight quote. This oven requires a custom crate to ship ($100 additional crating fee).

Licensed Electrician required for the installation of the SubliPro Mug Oven Ovens are manufactured voltage-specific (voltage cannot be changed once manufactured). Prior to shipping, they are wired for either single or 3-phase

Both 208 and 240V electrical equipment need adequate plugs. Below is a description of those voltage-appropriate plugs and other electrical requirements.

All Countertop Sublimation Ovens come with an adequate power cord, plug and matching receptacle

For Single Phase hookup (208V or 240V), electrical requirements are:

• Cable: 8/3 SOOW cable (This is 8-gauge wire and 3 conductors)



• Plug: can be any single phase plug that is rated for 50 amps.



• Receptacle: Matching receptacle rated for 50 amps.

included in this package is a NEMA 10-50P plug plus receptacle

For 3-phase hookup (208V or 240V), electrical requirements are:

•


• Cable: 10/4 SOOW cable (This would 10-gauge wire and 4 conductors)



• Plug: can be any 3-phase plug that is rated for 30 Amps or more.



• Receptacle: Matching receptacle for the plug rated at 30 amps or more.

included in this package is a NEMA 14-30P plug with receptacle
