HIX LF4464

HIX LF4464

$23,000.00

In stock

LF4464 SOLO

Size:

The LF-4464 large format sublimation press from HIX uses edge-to-edge heating element technology to utilize nearly the entire 44? x 64? platen and increase your throughput. More platen coverage means more capability. The LF-4464 sublimation press is designed to handle a wide variety of materials with superior results. Substrates include synthetic textiles for all-over printing, any sublimation-ready aluminum photographic sheets, MDF and glass plates, any flat plastic substrates up to five inches thick.


--

HIX LARGE FORMAT HEAT PRESS



Overview



The HIX LF-4464 is the first in a series of large format sublimation presses specifically designed for the non-textile as well as the textile sublimation market.



Using edge-to-edge heating element technology, the press handles a wide variety of materials and increases throughput with nearly full use of the entire work surface. Substrates include any sublimation-ready aluminum photographic sheets, MDF and glass plates, any flat plastic substrates as well as synthetic textiles.



The HIX LF-4464 is a pneumatic press with a 44 x 64” single or dual lower platen.

Features





  • Made of high-end materials as well as full-platen covering heating elements, resulting in very equal heat distribution and perfect color-consistency on any substrate, allowing for transfer process up to the very edges of the working platens.


  • 360? access to lower platen, allowing large printable products (such as awnings or large textile signs) to be safely tucked away while printing on parts of its surface.


  • Height-adjustable lower platens, allowing for wide variety of substrate thicknesses (up to 5”).


  • Superior quality transfers on both non-textile and textile substrates.


  • Simultaneous preparation of substrates while working independently on both platens (dual platen option);


  • Safety features provide proper hand protection for operators.


  • High-efficiency heat insulation for safety and reduced energy consumption.




Specifications



Base Plate Dimensions - 64" x 44"



Dimensions (SOLO) - 77.2" x 98.4" x 55.5"



Dimensions (TWIN) - 77.2" x 148" x 55.5"



Working Height - 35.4" - 37.8"



Weight (SOLO/TWIN) - 1630lbs/1890lbs



Heating Power - 13.5kW



Electric Connection - 230 VAC (3P G) 50/60Hz



Amperage - 37 Amps



Pneumatic Connection - 116psi



Max Printing Pressure at 116psi - 10lbs/sq.in



Printing Time - 0-9999 sec.



Temperature - Up to 410F
